Power Distribution System
Combined Cabinet 250A Delixi Combined Distribution Cabinet 31-Circuit
Combined Cabinet 250A Delixi Combined Distribution Cabinet 31-Circuit
Package price¥28,737.21
Bill of materials
| Brand | Model | Qty | Price | |
|---|---|---|---|---|
| Totem | Rack W600*H2000*D800 | 1 | ¥1,800.00 | |
| Delixi | CDQ3HB-250S/4P 160A | 1 | ¥2,342.40 | |
| Delixi | DZ47s C 4P 50A | 1 | ¥16.04 | |
| Delixi | CDM3-160S/3300 160A | 1 | ¥204.24 | |
| Delixi | DZ47s C 3P 63A | 2 | ¥11.74 | |
| Delixi | DZ47s C 3P 40A | 3 | ¥11.26 | |
| Delixi | DZ47s C 3P 32A | 3 | ¥9.95 | |
| Delixi | DZ47s C 2P 32A | 1 | ¥6.76 | |
| Delixi | DZ47s C 1P 63A | 1 | ¥3.77 | |
| Delixi | DZ47s C 1P 25A | 4 | ¥3.22 | |
| Delixi | DZ47s C 1P 20A | 1 | ¥3.22 | |
| Delixi | DZ47s C 1P 16A | 8 | ¥3.22 | |
| Delixi | DZ47s C 1P 10A | 8 | ¥3.22 | |
| Domestic high quality | Interphase separator 1 strings 6 pieces | 1 | ¥50.00 | |
| Delixi | DZ47sOF status indication contact | 33 | ¥8.32 | |
| Delixi | DZ47s shunt auxiliary AC 110V-415V | 1 | ¥26.95 | |
| Domestic high quality | LC-C40/2P | 1 | ¥240.00 | |
| Acrel | 7 inch Touchscreen FE4070CE-A | 1 | ¥1,275.00 | |
| Acrel | Main -Circuit Module AMC16Z-ZA | 1 | ¥293.00 | |
| Domestic high quality | LC 200/5 | 4 | ¥42.00 | |
| Domestic high quality | LC 100/5 | 2 | ¥34.88 | |
| Wong Wen | W-8 5-60A/20mA | 48 | ¥37.50 | |
| National standard | Copper busbar | 17 | ¥100.00 | |
| Acrel | Sub-Circuit Switch Volume AMC16Z-KD | 1 | ¥540.00 | |
| Domestic high quality | LC-B80/4P | 1 | ¥520.00 | |
| Acrel | Branch-Circuit Module AMC16Z-FA | 2 | ¥460.00 |
