Power Distribution System
Combined Distribution Cabinet CHINT 250A 4P 14-Circuit (Variant)
CHINT Combined Distribution Cabinet 250A 4P
Package price¥13,142.31
Bill of materials
| Brand | Model | Qty | Price | |
|---|---|---|---|---|
| Totem | Rack W600*H2000*D1000 | 1 | ¥2,000.00 | |
| CHINT ELECTRICAL APPLIANCES | NB1-63 4P C63 6kA(R) | 1 | ¥37.63 | |
 | CHINT ELECTRICAL APPLIANCES | NXB-63 4P C32 | 1 | ¥22.86 |
 | CHINT ELECTRICAL APPLIANCES | NXM-250S/3300 250A | 1 | ¥205.00 |
| CHINT ELECTRICAL APPLIANCES | NXM-160S/3300 160A | 1 | ¥217.44 | |
| Delixi | CDM3-100S/3320 100A | 3 | ¥334.00 | |
| CHINT ELECTRICAL APPLIANCES | NXB-63 3P C63 | 3 | ¥19.85 | |
| CHINT ELECTRICAL APPLIANCES | NXB-63 3P D32 | 2 | ¥18.42 | |
 | CHINT ELECTRICAL APPLIANCES | NXB-63 1P C32 | 6 | ¥5.44 |
| CHINT ELECTRICAL APPLIANCES | NB1-63 1P D16 6kA(R) | 3 | ¥8.53 | |
| CHINT | SHT-X1 shunt trip Unit AC230V/400V (environmental protection) | 1 | ¥10.11 | |
| Domestic high quality | Interphase separator 1 strings 6 pieces | 5 | ¥50.00 | |
| Domestic high quality | AM1-80/4 | 1 | ¥273.00 | |
| Domestic high quality | AM2-40/4 | 1 | ¥138.00 | |
| Acrel | Touchscreen ATP007 | 1 | ¥600.00 | |
| Acrel | Main -Circuit Module AMC16Z-ZA | 1 | ¥293.00 | |
| Domestic high quality | LC 250/5 | 3 | ¥47.00 | |
| National standard | Copper busbar | 12 | ¥100.00 |
Request a quote
Leave your details and an engineer will get back to you within one business day.
