Kohler
Kohler KL-3100
Price on request
- Rated power
- 12KW (kW)
- Maximum power
- 12KW (kW)
- Oil type
- Petrol
- Fuel tank capacity
- 37L (L)
- Startup method
- Electric start
- Net weight
- 150 kg (kg)
- Dimensions (L×W×H)
- 930×610×650mm (millimeters)
View on mobileDetailed specifications:
| Model | KL-3100 | |
| Generator | Rated voltage | Three-phase 400V |
| Frequency | 50Hz | |
| Maximum output | 12.5KVA | |
| Rated output | 11.5KVA | |
| Rated current | Each phase 14A | |
| Power factor | 0.8 | |
| Waveform distortion rate | < 4% | |
| Insulation class | Stator and rotor: Class H | |
| Engine | Type | "Imported from the United States" air-cooled four-stroke OHV dual-cylinder gasoline engine |
| Model displacement | CH20，624CC | |
| Maximum power | 20PS/3,600rpm | |
| Starting method | Electric start | |
| Fuel | More than 90# gasoline | |
| Oil capacity (L) | 1.9 | |
| Accessory Configuration | permanent magnet brushless electric ball | There is/are |
| Fuel tank capacity | 37L | |
| Oil alarm | There is/are | |
| Voltage indicator | There is/are | |
| Current indicator | There is/are | |
| Frequency table | Optional equipment | |
| Operating schedule | There is/are | |
| FUEL INDICATING Gage | There is/are | |
| Battery capacity | 12V-33AH Maintenance-free Battery | |
| Caster Accessories | Standard Equipped | |
| Other | Dimensions (Length x Width x Height) | 930x610x650 |
| Net weight | 150kg | |
| Fuel consumption [full load] | 4.0 liters/hour | |
| Continuous operation time | 9 hours | |
| Noise level 7M | 75db | |
