Santak
Santak 3C10KS
VAT invoice can be issued for postage in most areas of the 10K long machine
¥9,861.10List price ¥10424.00
- Rated power
- 9KW (kW)
- Rated capacity
- 10KVA (KVA)
- Input / output
- Three-in single-out (380V:220V)
- External battery voltage
- (long machine) 192V (DC)
- Blocks per string
- 16 pieces
- Net weight
- 16.90kg (kg)
- Gross weight
- 16.90kg (kg)
- Dimensions (L×W×H)
- 212*500*420mm (mm) 420U
UPS runtime configurations
View on mobileDetailed specifications:
Santak 3C10KS Output
| Output power Capacity | 9KW / 10 KVA |
| Rated output voltage | 220VAC |
| Output frequency | Synchronization with mains 50 Hz +/- 0.5% Hz |
| UPS Transfer time | 0ms |
| Output waveform | Sine wave |
| Overload capacity | At 110%–150%, the output remains in bypass mode for 30 seconds; above 150%, it stays in bypass for 300 ms. |
| Output form x quantity | Terminal block X1 |
Santak 3C10KS Input
| Rated input voltage | 304~478VAC |
| Input frequency | 40–60Hz (adjustable) |
| UPS power supply Efficiency | 85.0% |
| Automatic restart | After the battery is SHUTDWN, when the mains power returns to normal, it can automatically restart |
Communication and Management
| Interface Port | Wedpower card, AS400 card |
| Control Panel | LED |
| audible alarm | Mains power outage alarm once 4 seconds: special low battery alarm once per second |
| UPS abnormal | continuous beep |
Santak 3C10KS battery and running time
| Battery Model | Maintenance-free sealed lead-acid battery |
| Typical charging time | 10 hours |
| External battery specifications | DC192V |
| Backup time | 30 minutes to 8 hours optional |
Santak 3C10KS Physical Indicators
| W | 500.00 mm |
| D | 212.00 mm |
| H | 420.00 mm |
| Net weight | 16.90KG |
Santak 3C10KS Environment
| Operating environment | 0 - 40 °C |
| Operating relative humidity | 0 - 95% |
| Operating height | 0-3000 m |
| Storage temperature | -5 - 45 °C |
| Storage Relative Humidity | 0 - 95% |
| Storage height | 0-15000 m |
| Audible noise 1 m from equipment surface | 40.00 dBA |
| Standard warranty | Maintenance within 3 years |
| Compliance with environmental requirements | RoHS,REACH: does not contain SVHC |
