Detailed specifications:
1. The voltage is more stable: the latest damping winding technology is adopted, and the damping winding and inclined plane are added to the rotor to correct the magnetic field distortion and reduce the generation of clutter. 2, a wider range of uses: excellent waveform makes it more suitable for high-precision electronic waveform requirementsInstrumentthe computer,LampUPS, LED and other equipment. 3. High efficiency and energy saving: Yamaha OHV 4-stroke engine with high efficiency and energy saving, strong horsepower, low fuel consumption and high durability are the perfect embodiment of Yamaha engine technology.
1. The lightest weight in the same power output model 2. Portable design 3. Provide high-quality power 4. High power output 5. Low fuel consumption 6. Silent design 7. Environmental protection design 8. Excellent operating performance and reliability
Generator
Phase number single phase
Rated output 0.9KVA
Maximum output 1.0KVA
Power factor 1
Motor type Multi-stage rotating magnetic pole type
Rated voltage 220V
Rated current 4.1A
Frequency 50Hz
DC output 12V-8A
Engine
Engine type 4-stroke air-cooled OHV
Displacement 50CC
Rated power 1.21kw/3600rpm
Start Mode Hand Start
Tank capacity 2.5 litres
Continuous operation time 14.5-4.3 hours (no load-full load)
Lubricating oilCapacity 0.32 liters
Noise level 48-57dBA/7 m
Accessory device
Overload protection device (AC) electronicCircuit breaker
Overload protection device (DC) No fuse circuit breaker (NFB)
Fuel gauge-
Voltmeter-
Output indicator light
Overload indicator light
Oil warning lamp
Energy-saving idle device
Automatic wind resistancedoor -
Other
Size (length * width * height) 450X240X380mm
Net weight 12.7kg
