Santak 3C3PRO-160KS

Three-in, single-out, three-in, three-out, online high-frequency pilots include tax in most areas

Price on request

Ratings

UPS runtime configurations

View on mobile

Series Introduction

Detailed specifications:

3C3PRO-160KS Output

Topological structure	IGBT,PWM modulation technology
Rated input voltage	380Vac/220Vac
Voltage range	-50% ~ 20%, depending on the load
Power factor	0.99
THDI	＜5%
Frequency	50/60Hz adaptive
Frequency range	42-72Hz

Battery type	VRLA-sealed valve-regulated lead-acid battery
Backup time	Depending on battery capacity and working conditions
Number of battery cells	Section 36-40 optional, default 40
Charging time	8 hours to reach 90% full capacity

Standard communication interface	RS-232,Mini-Slot Communication Slot
Communication accessories (optional)	Modbus/Ethemet card; AS/400 card (standard);NMC card

Dimensions (WDH)mm	6008301876
Net weight （Kg）	457

Standard warranty

Maintenance within 3 years

160KVA input AC 380V: output AC 380V

Input parameter
Input voltage	380V AC
Input live conductor size	125mm²
Input neutral conductor size	125mm²
Input earth conductor size	125mm²
Input breaker	350A -Input AC 380V: Output AC 380V
Output parameter
Output voltage	380V AC
Output conductor size	100mm²
Output neutral conductor size	100mm²
Output earth conductor size	100mm²
Output breaker	300A -Input AC 380V: Output AC 380V
Battery specifications
External battery breaker	600A-Input AC 380V: Output AC 380V
External battery cable size	200mm²
