SPD5KCB

Name: SPD5KCB
SKU: 50
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	220V
Maximum total load current	30A
Output Connections	(4) Hard Wire 3-wire (H N + G);(8) IEC 320 C13;(2) IEC 320 C19
Overload protection	Yes
Input
Rated input voltage	220V
Input frequency	50/60Hz /- 3Hz (automatic adaptation)
Adjusted Reduced Input Current (North America)	25A
Input terminal type	Hard Wire 3 wire (1PH+N+G)
Acceptable Input Voltage	180-264 VAC
Maximum line current per phase	30A
Maximum input current	30A
Load capacity	5000kVA
Physical indicators
Net weight	9.90KG
High	132.00 mm
Wide	432.00 mm
deep	425.00 mm
Transport weight	15.20KG
Transportation height	281.00 mm
Transport width	596.00 mm
Transport length	494.00 mm
Colour	Black
Quantity of products on each transport pallet	24.00
Environment
Operating environment	-5-45°C
Operating relative humidity	5-95%
Operating height	0-3000 m
Storage temperature	-25 - 65°C
Storage Relative Humidity	5-95%
Storage height	0-15000 m
Conformity
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
REACH	REACH: No SVHC
Battery Directive	Conform to
Battery Precautions	Contains Lithium Coin Cell

Data not yet provided
