SPD20KCB

Name: SPD20KCB
SKU: 47
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	220V
Maximum total load current	125A
Output Connections	(6) Hard Wire 3-wire (H N + G)；(6) IEC 320 C13；(1) IEC 320 C19
Overload protection	Yes
Input
Rated input voltage	220V
Input frequency	50/60Hz /- 3Hz (automatic adaptation)
Adjusted Reduced Input Current (North America)	105A
Input terminal type	Hard Wire 3 wire (1PH+N+G)
Acceptable Input Voltage	180-264 VAC
Maximum line current per phase	125A
Maximum input current	125A
Load capacity	20kVA
Physical indicators
Net weight	13.60KG
High	176.00 mm
Wide	432.00 mm
deep	425.00 mm
Transport weight	19.20KG
Transportation height	319.00 mm
Transport width	596.00 mm
Transport length	494.00 mm
Colour	Black
Quantity of products on each transport pallet	20.00
Environment
Operating environment	-5-45°C
Operating relative humidity	5-95%
Operating height	0-3000 m
Storage temperature	-25 - 65°C
Storage Relative Humidity	5-95%
Storage height	0-15000 m
Conformity
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
REACH	REACH: No SVHC
Battery Directive	Conform to
Battery Precautions	Contains Lithium Coin Cell

Data not yet provided
