AP8453

Name: AP8453
SKU: 40
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	230V
Maximum total load current	32A
Output Connections	(21) IEC 320 C13;(3) IEC 320 C19
Overload protection	Yes
Input
Rated input voltage	200V, 208V, 230V
Input frequency	50/60Hz
Input terminal type	IEC 309 32A 2P+E
Input line length	3.05 m
Number of power cords	1
Acceptable Input Voltage	220-240 VAC
Maximum line current per phase	32A
Maximum input current	32A
Physical indicators
Net weight	8.21KG
High	1829.00 mm
Wide	56.00 mm
deep	51.00 mm
Transport weight	10.48KG
Transportation height	2037.00 mm
Transport width	163.00 mm
Transport length	117.00 mm
Colour	Black
Quantity of products on each transport pallet	48.00
Environment
Operating environment	-5-45°C
Operating relative humidity	5-95%
Operating height	0-3000 m
Storage temperature	-25 - 65°C
Storage Relative Humidity	5-95%
Storage height	0-15000 m
Conformity
Management body certification	EN 55022, Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, VDE
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
REACH	REACH: No SVHC
Battery Directive	Conform to
Battery Precautions	Contains Lithium Coin Cell

Data not yet provided
