AP6453CH

Name: AP6453CH
SKU: 36
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	220V
Maximum total load current	32A
Output Connections	(18) IEC 320 C13;(6) IEC 320 C19
Input
Rated input voltage	220V
Input frequency	50Hz
Input terminal type	IEC 309 16A 2P+E
Input line length	2 meters
Number of power cords	1
Maximum input current	32A
Load capacity	7040VA
Physical indicators
Net weight	5.30KG
High	1600.00 mm
Wide	56.00 mm
deep	44.00 mm
Transport weight	6.30KG
Transportation height	1809.00 mm
Transport width	156.00 mm
Transport length	96.00 mm
Colour	Black
Environment
Operating environment	-5-45°C
Operating relative humidity	5-95%
Operating height	0-3000 m
Storage temperature	-25 - 65°C
Storage Relative Humidity	5-95%
Storage height	0-15000 m
Conformity
Management body certification	CE
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
REACH	REACH: No SVHC
Other Environmental Compliance	China RoHS
