AP7526

Name: AP7526
SKU: 37
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	230V
Maximum total load current	32A
Output Connections	(6) IEC 320 C19
Overload protection	Yes
Input
Rated input voltage	400V 3PH
Input frequency	47-63Hz
Input terminal type	IEC 309 32A 3P+N+PE
Input line length	2.44 meters
Number of power cords	1
Acceptable Input Voltage	200-250 VAC
Maximum line current per phase	32A
Maximum input current	32A
Physical indicators
Net weight	4.84KG
High	44.00 mm
Wide	437.00 mm
deep	254.00 mm
Transport weight	6.98KG
Transportation height	241.00 mm
Transport width	559.00 mm
Transport length	502.00 mm
Colour	Black
Environment
Operating environment	-5-45°C
Operating relative humidity	5-95%
Operating height	0-3000 m
Storage temperature	-25 - 65°C
Storage Relative Humidity	5-95%
Storage height	0-15000 m
Conformity
Management body certification	CE, GOST, VDE
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
REACH	REACH: No SVHC
PEP	Available in Documentation tab
EOLI	Available in Documentation tab

Data not yet provided
