AP9572

Name: AP9572
SKU: 31
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	200V，208V, 230V
Maximum total load current	16A
Output Connections	(15) IEC 320 C13
Input
Rated input voltage	200V, 208V, 230V
Input frequency	50/60Hz
Input terminal type	IEC-320 C20
Input line length	2.5 m
Number of power cords	1
Maximum line current per phase	16A
Maximum input current	16A
Load capacity	3680VA
Physical indicators
Net weight	2.00KG
High	620.00 mm
Wide	44.00 mm
deep	44.00 mm
Transport weight	2.73KG
Transportation height	638.00 mm
Transport width	168.00 mm
Transport length	146.00 mm
Colour	Black
Environment
Operating environment	0-45°C
Operating relative humidity	5-95%
Operating height	0-3000 m
Storage temperature	-25 - 65°C
Storage Relative Humidity	5-95%
Storage height	0-15000 m
Conformity
Management body certification	cUL Listed, CE, Concise status message LED, UL 60950, UL listed, VDE
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
PEP	Available in Documentation tab
EOLI	Available in Documentation tab
Other Environmental Compliance	China RoHS

Data not yet provided
