AP9568

Name: AP9568
SKU: 30
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	208V, 230V
Maximum total load current	10A
Output Connections	(15) IEC 320 C13
Input
Rated input voltage	200V, 208V, 230V
Input frequency	50/60Hz
Input terminal type	IEC-320 C14
Input line length	1.98 meters
Number of power cords	1
Acceptable Input Voltage	200-240 VAC
Maximum input current	10A
Load capacity	2300VA
Physical indicators
Net weight	2.00KG
High	610.00 mm
Wide	44.00 mm
deep	44.00 mm
Transport weight	2.73KG
Transportation height	648.00 mm
Transport width	178.00 mm
Transport length	152.00 mm
Colour	Black
Environment
Operating environment	0-45°C
Operating relative humidity	0-95%
Operating height	0-3000 m
Storage temperature	-25 - 65°C
Storage Relative Humidity	0-95%
Storage height	0-15000 m
Conformity
Management body certification	cUL Listed, CE, GOST, Concise status information LED, UL listed, VDE
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
REACH	REACH: No SVHC
PEP	Available in Documentation tab
EOLI	Available in Documentation tab
Other Environmental Compliance	China RoHS

Data not yet provided
