AP7921

Name: AP7921
SKU: 3
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	208V, 230V
Maximum total load current	16A
Output Connections	(8) IEC 320 C13
Input
Rated input voltage	200V, 208V, 230V
Input frequency	50/60 Hz
Adjusted Reduced Input Current (North America)	16A
Input terminal type	IEC-320 C20
Input line length	2.5 m
Number of power cords	1
Acceptable Input Voltage	200-240 VAC
Maximum input current	20A
Load capacity	3680 VA
Physical indicators
Net weight	2.27 KG
High	44.00 mm
Wide	445.00 mm
deep	108.00 mm
Transport weight	3.45 KG
Transportation height	70.00 mm
Transport width	470.00 mm
Transport length	343.00 mm
Colour	Black
Environment
Operating environment	0-45°C
Operating relative humidity	0-95%
Operating height	0-3000 m
Storage temperature	0-25 - 65°C
Storage Relative Humidity	0-95%
Storage height	0-15000 m
Conformity
Management body certification	cUL Listed, CE, CSA, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, IRAM, MIC, UL 60950, UL as listed, VDE, VCCI
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
REACH	REACH: No SVHC
PEP	Available in Documentation tab
EOLI	Available in Documentation tab
Other Environmental Compliance	China RoHS

Data not yet provided
