AP7950

Name: AP7950
SKU: 5
Availability: InStock

Price on request

Ratings

View on mobile

Detailed specifications:

Output
Rated output voltage	230V
Maximum total load current	10A
Output Connections	(16) IEC 320 C13
Overload protection	No
Input
Rated input voltage	200V, 208V, 230V
Input frequency	47-63 Hz
Input terminal type	IEC-320 C14
Input line length	3.05 m
Number of power cords	1
Acceptable Input Voltage	200-240 VAC
Maximum line current per phase	10A
Maximum input current	10A
Load capacity	7360 VA
Physical indicators
Net weight	4.32 KG
High	1245.00 mm
Wide	56.00 mm
deep	44.00 mm
Transport weight	5.23 KG
Transportation height	2134.00 mm
Transport width	152.00 mm
Transport length	127.00 mm
Colour	Black
Environment
Operating environment	-5-45°C
Operating relative humidity	5-95%
Operating height	0-3000 m
Storage temperature	-25 - 65°C
Storage Relative Humidity	5-95%
Storage height	0-15000 m
Conformity
Management body certification	CE, EN 55022, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, IRAM, VDE
Standard warranty	Repair or replacement within 2 years
Sustainable provision status
RoHS	Conform to
REACH	REACH: No SVHC
PEP	Available in Documentation tab
EOLI	Available in Documentation tab
Battery Directive	Conform to
Other Environmental Compliance	China RoHS

Data not yet provided

Power Distribution Units (PDU)
